7.3 Power Sleep Controller (PSC)
The Power Sleep Controller (PSC) controls overall device power by turning off unused power domains and gating
off clocks to individual peripherals and modules. The PSC provides the user with an interface to control several
important power and clock operations.
For information on the Power Sleep Controller, see the Power Sleep Controller (PSC) for KeyStone Devices User
Guide in ‘‘Related Documentation from Texas Instruments’’ on page 69.
7.3.1 Power Domains
The device has several power domains that can be turned on for operation or off to minimize power dissipation. The
global power/sleep controller (GPSC) is used to control the power gating of various power domains.
Table 7-6 shows the TMS320C6672 power domains.
Table 7-6
Power Domains
Domain
Block(s)
Note
Power Connection
Always on
0
Most peripheral logic
Per-core TETB and System TETB
Packet Coprocessor
PCIe
Cannot be disabled
RAMs can be powered down
Logic can be powered down
Logic can be powered down
Logic can be powered down
Logic can be powered down
Reserved
1
Software control
Software control
Software control
Software control
Software control
Reserved
2
3
4
SRIO
5
HyperLink
6
Reserved
7
MSMC RAM
MSMC RAM can be powered down
L2 RAMs can sleep
L2 RAMs can sleep
Reserved
Software control
8
C66x CorePac 0, L1/L2 RAMs
C66x CorePac 1, L1/L2 RAMs
Reserved
Software control via C66x core. For details, see the
C66x CorePac Reference Guide.
9
10
11
12
13
14
15
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
End of Table 7-6
