TMDS361B
www.ti.com
SLLS988A –SEPTEMBER 2009–REVISED JULY 2011
Acknowledge
(From Receiver)
Acknowledge
(Receiver)
Acknowledge
(Receiver)
Start
Condition
ACK
ACK
ACK
A6
A5
A1 A0 R/W
D7 D6
D1 D0
D7 D6
D1 D0
SDA
I2C Device Address and
Read/Write Bit
Stop
Condition
Other
Data Bytes
First Data Byte
Last Data Byte
T0397-01
Figure 53. Multiple-Byte Write Transfer
A = No Acknowledge (SDA High)
A = Acknowledge
S = Start Condition
P = Stop Condition
W = Write
R
A
Data
A
Data
A
P
S
Slave Address
Transmitter
R = Read
Receiver
R0008-01
Figure 54. I2C Read Cycle
Start
Condition
Acknowledge Acknowledge
(From Receiver) (From Transmitter)
Not Acknowledge
(Transmitter)
ACK
ACK
A6
A0
R/W
D7
D0
D7 D6
D1 D0 ACK
SDA
I2C Device Address and
Read/Write Bit
Stop
Condition
First Data
Byte
Other Last Data Byte
Data Bytes
T0398-01
Figure 55. Multiple-Byte Read Transfer
Slave Address
Both SDA and SCL must be connected to a positive supply voltage via pullup resistors. These resistors should
comply with the I2C specification that ranges from 2 kΩ to 19 kΩ. When the bus is free, both lines are high. The
address byte is the first byte received following the START condition from the master device. The 7-bit address is
factory preset to 0101 100. Table 7 lists the calls to which the TMDS361B responds.
Table 7. TMDS361B Slave Address
FIXED ADDRESS
READ/WRITE BIT
Bit 0 (R/W)
1/0
Bit 7 (MSB)
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
0
1
0
1
1
0
0
EXAMPLE – WRITING TO THE TMDS361B
The proper way to write to the TMDS361B is illustrated as follows:
An I2C master initiates a write operation to the TMDS361B by generating a start condition (S) followed by the
TMDS361B I2C address (as shown following, in MSB-first bit order, followed by a 0 to indicate a write cycle. After
receiving an acknowledge from the TMDS361B, the master presents the subaddress (sink port) to be written,
consisting of one byte of data, MSB-first. The TMDS361B acknowledges the byte after completion of the transfer.
Finally, the master presents the data to be written to the register (sink port), and the TMDS361B acknowledges
the byte. The master can continue presenting data to be written after the TMDS361B acknowledges the previous
byte (steps 6, 7). After the last byte to be written has been acknowledged by the TMDS361B, the I2C master then
terminates the write operation by generating a stop condition (P).
Step 1
0
I2C start (master)
S
