TMDS361B
SLLS988A –SEPTEMBER 2009–REVISED JULY 2011
www.ti.com
5 V
SCL[x]
SDA[x]
Input
1.6 V
0.1 V
tPHL2
tPLH2
5 V
80%
SCL_SINK
SDA_SINK
Output
1.6 V
VOL
20%
tf2
T0388-01
Figure 6. Source-Side Output AC Measurements
5 V
SCL_SINK
SDA_SINK
Input
1.6 V
0.1 V
tPHL1
5 V
80%
SCL[x]
SDA[x]
Output
1.6 V
VOL
20%
tf1
T0389-01
Figure 7. Sink-Side Output AC Measurements
5 V
SCL_SINK
SDA_SINK
Input
VOL
tPLH1
5 V
SCL[x]
SDA[x]
Output
1.6 V
T0390-01
Figure 8. Source-Side Output AC Measurements (Continued)
TMDS Main Link Pins
The TMDS port of the TMDS361B is designed to support the Digital Video Interface (DVI) 1.0 and High Definition
Multimedia Interface (HDMI) 1.3 specifications. The differential output voltage swing can be fine-tuned with the
VSadj resistor.
14
