PACKAGE OPTION ADDENDUM
www.ti.com
24-Jan-2013
PACKAGING INFORMATION
Orderable Device
TLV320A1103PBSRG4
TLV320AIC1103GQER
Status Package Type Package Pins Package Qty
Eco Plan Lead/Ball Finish
MSL Peak Temp
Op Temp (°C)
Top-Side Markings
Samples
Drawing
(1)
(2)
(3)
(4)
ACTIVE
TQFP
PBS
32
80
1000
Green (RoHS
& no Sb/Br)
CU NIPDAU
Call TI
Level-3-260C-168 HR
-40 to 85 AIC1103
OBSOLETE
BGA
GQE
TBD
Call TI
-40 to 85
AIC1103
MICROSTAR
JUNIOR
TLV320AIC1103PBS
TLV320AIC1103PBSG4
TLV320AIC1103PBSR
TLV320AIC1103ZQER
ACTIVE
ACTIVE
ACTIVE
ACTIVE
TQFP
TQFP
TQFP
PBS
PBS
PBS
ZQE
32
32
32
80
250
250
Green (RoHS
& no Sb/Br)
CU NIPDAU
CU NIPDAU
CU NIPDAU
SNAGCU
Level-3-260C-168 HR
Level-3-260C-168 HR
Level-3-260C-168 HR
Level-3-260C-168 HR
-40 to 85
-40 to 85
-40 to 85
AIC1103
AIC1103
AIC1103
AIC1103
Green (RoHS
& no Sb/Br)
1000
2500
Green (RoHS
& no Sb/Br)
BGA
MICROSTAR
JUNIOR
Green (RoHS
& no Sb/Br)
(1) The marketing status values are defined as follows:
ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in a new design.
PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.
(2) Eco Plan - The planned eco-friendly classification: Pb-Free (RoHS), Pb-Free (RoHS Exempt), or Green (RoHS & no Sb/Br) - please check http://www.ti.com/productcontent for the latest availability
information and additional product content details.
TBD: The Pb-Free/Green conversion plan has not been defined.
Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements for all 6 substances, including the requirement that
lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.
Pb-Free (RoHS Exempt): This component has a RoHS exemption for either 1) lead-based flip-chip solder bumps used between the die and package, or 2) lead-based die adhesive used between
the die and leadframe. The component is otherwise considered Pb-Free (RoHS compatible) as defined above.
Green (RoHS & no Sb/Br): TI defines "Green" to mean Pb-Free (RoHS compatible), and free of Bromine (Br) and Antimony (Sb) based flame retardants (Br or Sb do not exceed 0.1% by weight
in homogeneous material)
(3) MSL, Peak Temp. -- The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder temperature.
(4) Only one of markings shown within the brackets will appear on the physical device.
Addendum-Page 1
