Write 1’b1 to E.3 DATAPATH_RESET
•
Clear Latched Registers
–
Read 0x0F CHANNEL_STATUS_1 to clear (per channel)
•
•
Device provisioning has completed at this point
Periodically Check Device Operational Mode Status (Non-Errored Read Values Shown Below):
–
Read 0x0F CHANNEL_STATUS_1 and verify the following bits:
–
–
–
–
–
–
–
–
–
–
–
–
–
–
F.14 LA_SLAVE_STATUS (1’b1) (per channel)
F.13 HS_LOS (1’b0) (per channel)
F.12 HS_AZ_DONE (1’b1) (per channel)
F.11 HS_AGC_LOCKED (1’b1) (per channel)
F.10 HS_CHANNEL_SYNC (1’b1) (per channel)
F.8 HS_DECODE_INVALID (1’b0) (per channel)
F.7 TX_FIFO_UNDERFLOW (1’b0) (per channel)
F.6 TX_FIFO_OVERFLOW (1’b0) (per channel)
F.5 RX_FIFO_UNDERFLOW (1’b0) (per channel)
F.4 RX_FIFO_OVERFLOW (1’b0) (per channel)
F.3 RX_LS_OK (1’b1) (per channel).
F.2 TX_LS_OK (1’b1) (per channel).
F.1 LS_PLL_LOCK (1’b1) (per channel)
F.0 HS_PLL_LOCK (1’b1) (per channel)
