TAS5711
www.ti.com
SLOS600 –DECEMBER 2009
2-Channel I2S (Philips Format) Stereo Input
16 Clks
16 Clks
LRCLK
Right Channel
Left Channel
SCLK
SCLK
MSB
LSB
1
MSB
LSB
16-Bit Mode
15 14 13 12 11 10
9
8
5
4
3
2
0
15 14 13 12 11 10
9
8
5
4
3
2
1
T0266-01
NOTE: All data presented in 2s-complement form with MSB first.
Figure 39. I2S 32-fS Format
Left-Justified
Left-justified (LJ) timing uses LRCLK to define when the data being transmitted is for the left channel and when it
is for the right channel. LRCLK is high for the left channel and low for the right channel. A bit clock running at 32,
48, or 64 × fS is used to clock in the data. The first bit of data appears on the data lines at the same time LRCLK
toggles. The data is written MSB first and is valid on the rising edge of the bit clock. The DAP masks unused
trailing data bit positions.
2-Channel Left-Justified Stereo Input
32 Clks
32 Clks
LRCLK
SCLK
Right Channel
Left Channel
SCLK
MSB
LSB MSB
23 22
LSB
24-Bit Mode
23 22
9
5
1
8
4
0
5
1
4
0
1
9
5
1
8
4
0
5
1
4
0
1
0
0
20-Bit Mode
19 18
19 18
15 14
16-Bit Mode
15 14
T0034-02
NOTE: All data presented in 2s-complement form with MSB first.
Figure 40. Left-Justified 64-fS Format
Copyright © 2009, Texas Instruments Incorporated
Submit Documentation Feedback
27
Product Folder Link(s): TAS5711
