4.4 Command Register
The PCI command register provides control over the PCI6x21/PCI6x11 interface to the PCI bus. All bit functions
adhere to the definitions in the PCI Local Bus Specification (see Table 4−3). None of the bit functions in this register
are shared among the PCI6x21/PCI6x11 PCI functions. Three command registers exist in the PCI6x21/PCI6x11
controller, one for each function. Software manipulates the PCI6x21/PCI6x11 functions as separate entities when
enabling functionality through the command register. The SERR_EN and PERR_EN enable bits in this register are
internally wired OR between the three functions, and these control bits appear to software to be separate for each
function.
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Name
Type
Default
Command
R
0
R
0
R
0
R
0
R
0
RW
0
R
0
RW
0
R
0
RW
0
RW
0
R
0
R
0
RW
0
RW
0
RW
0
Register:
Offset:
Type:
Command
04h
Read-only, Read/Write
0000h
Default:
Table 4−3. Command Register Description
FUNCTION
BIT
SIGNAL
TYPE
15−11
RSVD
R
Reserved. Bits 15−11 return 0s when read.
INTx disable. When set to 1, this bit disables the function from asserting interrupts on the INTx signals.
0 = INTx assertion is enabled (default)
10
9
INT_DISABLE
FBB_EN
RW
R
1 = INTx assertion is disabled
Fast back-to-back enable. The PCI6x21/PCI6x11 controller does not generate fast back-to-back
transactions; therefore, this bit is read-only. This bit returns a 0 when read.
System error (SERR) enable. This bit controls the enable for the SERR driver on the PCI interface. SERR
can be asserted after detecting an address parity error on the PCI bus. Both this bit and bit 6 must be set
for the PCI6x21/PCI6x11 controller to report address parity errors.
0 = Disables the SERR output driver (default)
8
7
6
SERR_EN
RSVD
RW
R
1 = Enables the SERR output driver
Reserved. Bit 7 returns 0 when read.
Parity error response enable. This bit controls the PCI6x21/PCI6x11 response to parity errors through the
PERR signal. Data parity errors are indicated by asserting PERR, while address parity errors are indicated
by asserting SERR.
PERR_EN
RW
0 = PCI6x21/PCI6x11 controller ignores detected parity errors (default).
1 = PCI6x21/PCI6x11 controller responds to detected parity errors.
VGA palette snoop. When set to 1, palette snooping is enabled (i.e., the PCI6x21/PCI6x11 controller does
not respond to palette register writes and snoops the data). When the bit is 0, the PCI6x21/PCI6x11
controller treats all palette accesses like all other accesses.
5
4
3
2
VGA_EN
MWI_EN
SPECIAL
MAST_EN
RW
R
Memory write-and-invalidate enable. This bit controls whether a PCI initiator device can generate memory
write-and-invalidate commands. The PCI6x21/PCI6x11 controller does not support memory
write-and-invalidate commands, it uses memory write commands instead; therefore, this bit is hardwired
to 0. This bit returns 0 when read. Writes to this bit have no effect.
Special cycles. This bit controls whether or not a PCI device ignores PCI special cycles. The
PCI6x21/PCI6x11 controller does not respond to special cycle operations; therefore, this bit is hardwired
to 0. This bit returns 0 when read. Writes to this bit have no effect.
R
Bus master control. This bit controls whether or not the PCI6x21/PCI6x11 controller can act as a PCI bus
initiator (master). The PCI6x21/PCI6x11 controller can take control of the PCI bus only when this bit is set.
0 = Disables the PCI6x21/PCI6x11 ability to generate PCI bus accesses (default)
RW
1 = Enables the PCI6x21/PCI6x11 ability to generate PCI bus accesses
4−4
