Table 6-91. Universal Serial Bus OTG (USB0) Registers (continued)
BYTE ADDRESS
Acronym
Register Description
0x01E0 051C
HOST_RXTYPE
Sets the operating speed, transaction protocol and peripheral endpoint
number for the host Receive endpoint.
0x01E0 051D
HOST_RXINTERVAL
Sets the polling interval for Interrupt/ISOC transactions or the NAK
response timeout on Bulk transactions for host Receive endpoint.
Control and Status Register for Endpoint 2
0x01E0 0520
0x01E0 0522
TXMAXP
Maximum Packet Size for Peripheral/Host Transmit Endpoint
PERI_TXCSR
Control Status Register for Peripheral Transmit Endpoint (peripheral
mode)
HOST_TXCSR
Control Status Register for Host Transmit Endpoint
(host mode)
0x01E0 0524
0x01E0 0526
RXMAXP
Maximum Packet Size for Peripheral/Host Receive Endpoint
PERI_RXCSR
Control Status Register for Peripheral Receive Endpoint (peripheral
mode)
HOST_RXCSR
Control Status Register for Host Receive Endpoint
(host mode)
0x01E0 0528
0x01E0 052A
RXCOUNT
Number of Bytes in Host Receive endpoint FIFO
HOST_TXTYPE
Sets the operating speed, transaction protocol and peripheral endpoint
number for the host Transmit endpoint.
0x01E0 052B
0x01E0 052C
0x01E0 052D
HOST_TXINTERVAL
HOST_RXTYPE
Sets the polling interval for Interrupt/ISOC transactions or the NAK
response timeout on Bulk transactions for host Transmit endpoint.
Sets the operating speed, transaction protocol and peripheral endpoint
number for the host Receive endpoint.
HOST_RXINTERVAL
Sets the polling interval for Interrupt/ISOC transactions or the NAK
response timeout on Bulk transactions for host Receive endpoint.
Control and Status Register for Endpoint 3
0x01E0 0530
0x01E0 0532
TXMAXP
Maximum Packet Size for Peripheral/Host Transmit Endpoint
PERI_TXCSR
Control Status Register for Peripheral Transmit Endpoint (peripheral
mode)
HOST_TXCSR
Control Status Register for Host Transmit Endpoint
(host mode)
0x01E0 0534
0x01E0 0536
RXMAXP
Maximum Packet Size for Peripheral/Host Receive Endpoint
PERI_RXCSR
Control Status Register for Peripheral Receive Endpoint (peripheral
mode)
HOST_RXCSR
Control Status Register for Host Receive Endpoint
(host mode)
0x01E0 0538
0x01E0 053A
RXCOUNT
Number of Bytes in Host Receive endpoint FIFO
HOST_TXTYPE
Sets the operating speed, transaction protocol and peripheral endpoint
number for the host Transmit endpoint.
0x01E0 053B
0x01E0 053C
0x01E0 053D
HOST_TXINTERVAL
HOST_RXTYPE
Sets the polling interval for Interrupt/ISOC transactions or the NAK
response timeout on Bulk transactions for host Transmit endpoint.
Sets the operating speed, transaction protocol and peripheral endpoint
number for the host Receive endpoint.
HOST_RXINTERVAL
Sets the polling interval for Interrupt/ISOC transactions or the NAK
response timeout on Bulk transactions for host Receive endpoint.
Control and Status Register for Endpoint 4
0x01E0 0540
0x01E0 0542
TXMAXP
Maximum Packet Size for Peripheral/Host Transmit Endpoint
PERI_TXCSR
Control Status Register for Peripheral Transmit Endpoint (peripheral
mode)
HOST_TXCSR
RXMAXP
Control Status Register for Host Transmit Endpoint
(host mode)
0x01E0 0544
Maximum Packet Size for Peripheral/Host Receive Endpoint
