MSP-TS430PN80USB
Jumper JP3
1-2 (int): Power supply via JTAG debug interface
2-3 (ext): External power supply
USB Connector
Connector J5
External power connector
Jumper JP3 to ‘ext’
Jumper JP1
Open to measure current
Jumper JP4
Close for USB bus powered
device
Jumper JP5 to JP10
Close 1-2 to debug in Spy-Bi-
Wire mode.
Close 2-3 to debug in 4-wire
JTAG mode.
BSL invoke button S3
LED connected to P1.0
Jumper JP2
Open to disconnect LED
Figure B-40. MSP-TS430PN80USB Target Socket Module, PCB
