MSP-TS430PN80USB
Table B-20. MSP-TS430PN80A Bill of Materials
No. per
Board
Position
Ref Des
Description
DigiKey Part No.
Comment
1
2
C1, C2
C3, C4
0
0
12pF, SMD0805
47pF, SMD0805
DNP
DNP
C6, C7,
C10, C12
3
3
10uF/6.3V, SMD0805
DNP C10
C5, C11,
C13, C14,
C15
4
5
100nF, SMD0805
311-1245-2-ND
478-1403-2-ND
5
6
7
8
9
C8
C9
1
1
1
1
1
2.2nF, SMD0805
470nF, SMD0805
4.7uF, SMD0805
220nF, SMD0805
green LED, SMD0805
C16
C17
D1
P516TR-ND
SAM1029-20-ND
(Header)
SAM1213-20-ND
(Receptacle)
DNP: Headers and receptacles
enclosed with kit. Keep vias free of
solder:
J1, J2, J3,
J4
10
11
12
0
2
7
20-pin header, TH
J5 , J6
3-pin header, male, TH
3-pin header, male, TH
JP3, JP5,
JP6, JP7,
JP8, JP9,
JP10
place jumpers on pins 2-3 on JP5,
JP6, JP7, JP8, JP9, JP10 place
jumpers on pins 1-2 on JP3,
SAM1035-03-ND
JP1, JP2,
JP4
13
14
15
3
10
1
2-pin header, male, TH
Jumper
SAM1035-02-ND
15-38-1024-ND
HRP14H-ND
Place jumper on header
See Pos. 12 and Pos. 13
14-pin connector, male,
TH
JTAG
10-pin connector, male,
TH
16
17
18
19
BOOTST
0
0
0
0
"DNP Keep vias free of solder"
DNP: Q1 Keep vias free of solder
DNP: Q2 Keep vias free of solder
Micro Crystal MS3V-T1R
32.768kHz, C(Load) =
12.5pF
Q1
Q2
Crystal
Q2: 4MHz Buerklin:
78D134
Crystal
http://www.ettinger.de/Ar
t_Detail.cfm?ART_ART
NUM=70.08.121
Insulating
disk to Q2
Insulating disk to Q2
20
21
D3,D4
2
2
LL103A
Buerklin: 24S3406
541-330ATR-ND
R3, R7
330 Ω, SMD0805
R1, R2,
R4, R6,
R8,
22
3
0 Ohm, SMD0805
541-000ATR-ND
DNP: R6, R8, R9, R10, R11,R12
R9,R10,
R11, R12
23
24
25
R5
U1
1
1
1
47k Ω, SMD0805
Socket:IC201-0804-014
77 x 91 mm
541-47000ATR-ND
Manuf.: Yamaichi
2 layers
PCB
Adhesive
plastic feet
about 6mm width, 2mm e.g., 3M Bumpons Part
26
27
4
2
Apply to corners at bottom side
height
No. SJ-5302
MSP430
MSP430F5329IPN
DNP: enclosed with kit, supplied by TI
B.20 MSP-TS430PN80USB
Due to the use of diodes in the power chain, the voltage on the MSP430F5xx device is approximately
0.3 V lower than is set by the debugging tool. Set the voltage in the IDE to 0.3 V higher than desired; for
example, to run the MCU at 3.0 V, set it to 3.3 V.
91
