MSP-TS430PN80A
www.ti.com
Jumpers JP5 to JP10
Close 1-2 to debug in Spy-Bi-Wire mode
Close 2-3 to debug in 4-wire JTAG mode
Connector J5
External power connector
Jumper JP3 to "ext"
If the system should
be supplied via LDOI (J6),
close JP4 and
set JP3 to external
Orient Pin 1 of MSP430 device
Jumper JP2
Open to disconnect LED
D1 LED connected to P1.0
Figure B-38. MSP-TS430PN80A Target Socket Module, PCB
