DM385, DM388
www.ti.com
SPRS821D –MARCH 2013–REVISED DECEMBER 2013
(
)
(
)
(
)
( ) ( )
(
)
DM385
AAR
PREFIX
PCIe
Blank = Production Device (TMS)
X = Pre-production Device
P = Prototype Device
Blank = Enabled on DM385, Disabled on DM388
P = Enabled on DM388
Face Detect
Blank = Disabled
F = Enabled
DEVICE
DEVICE SPEED RANGE
DM38x DaVinci™ Digital Media Processors
DM385
DM388
01 = 720-MHz ARM, 290-MHz HDVICP2
11 = 970-MHz ARM, 410-MHz HDVICP2
21 = 1000-MHz ARM, 450-MHz HDVICP2
TEMPERATURE RANGE
Blank = 0°C to 95°C, Commercial Temperature
D = -40°C to 95°C, Extended Temperature
SILICON REVISION
Blank = Revision 1.0
A = Revision 1.1
PACKAGE TYPE(A)
AAR = 609-Pin Plastic BGA, with Pb-Free Die Bump
and Solder Ball
Figure 9-1. Device Nomenclature
9.2 Documentation Support
Contact your TI sales representative for support documents.
For additional peripheral information, see the latest version of the DM38x DaVinci™ Digital Media
Processor Technical Reference Manual (Literature Number: SPRUHG1).
9.3 Community Resources
The following links connect to TI community resources. Linked contents are provided "AS IS" by the
respective contributors. They do not constitute TI specifications and do not necessarily reflect TI's views;
see TI's Terms of Use.
TI E2E Community TI's Engineer-to-Engineer (E2E) Community. Created to foster collaboration
among engineers. At e2e.ti.com, you can ask questions, share knowledge, explore ideas and
help solve problems with fellow engineers.
TI Embedded Processors Wiki Texas Instruments Embedded Processors Wiki. Established to help
developers get started with Embedded Processors from Texas Instruments and to foster
innovation and growth of general knowledge about the hardware and software surrounding
these devices.
Copyright © 2013, Texas Instruments Incorporated
Device and Documentation Support
275
Submit Documentation Feedback
Product Folder Links: DM385 DM388
