CC2510Fx / CC2511Fx
6.11 Control AC Characteristics
TA = 25°C, VDD = 3.0 V if nothing else stated. All measurement results are obtained using the
CC2510EM reference designs ([1]).
Parameter
Min
Typ
Max
Unit
Condition/Note
System clock,
fSYSCLK
CC2510Fx
tSYSCLK= 1/ fSYSCLK
0.1875
0.1875
26
13
27
MHz
MHz
High speed crystal oscillator used as source (HS XOSC)
Calibrated HS RCOSC used as source.
13.5
HS
HS
XOSC
RCOSC
111
000
000
111
Min: fXOSC = 24 MHz, CLKCON.CLKSPD=
Typ: fXOSC = 26 MHz, CLKCON.CLKSPD=
Max: fXOSC = 27 MHz, CLKCON.CLKSPD=
CC2511Fx
001
001
0.1875
0.1875
24
12
24
12
MHz
MHz
High speed crystal oscillator used as source.
HS RCOSC used as source.
HS
HS
XOSC
RCOSC
111
000
000
111
001
001
Min: fXOSC = 48 MHz, CLKCON.CLKSPD=
Typ: fXOSC = 48 MHz, CLKCON.CLKSPD=
Max: fXOSC = 48 MHz, CLKCON.CLKSPD=
RESET_N low
width
250
ns
See item 1, Figure 4. This is the shortest pulse that is
guaranteed to be recognized as a reset pin request.
Note: Shorter pulses may be recognized but will not lead to
complete reset of all modules within the chip.
Interrupt pulse
width
tSYSCLK
See item 2, Figure 4. This is the shortest pulse that is
guaranteed to be recognized as an interrupt request. In PM2/3
the internal synchronizers are bypassed so this requirement
does not apply in PM2/3.
Table 19: Control Inputs AC Characteristics
1
RESET_N
Px_n
2
2
Px_n
Figure 4: Control Inputs AC Characteristics
SWRS055F
Page 22 of 241
