bq4285E/L
Absolute Maximum Ratings—bq4285E
Symbol
Parameter
Value
Unit
Conditions
VCC
DC voltage applied on VCC relative to VSS
-0.3 to 7.0
V
DC voltage applied on any pin excluding VCC
relative to VSS
VT
V
T ≤ VCC + 0.3
-0.3 to 7.0
V
0 to +70
-40 to +85
-55 to +125
-40 to +85
260
°C
°C
°C
°C
°C
Commercial
TOPR
Operating temperature
Industrial “N”
TSTG
Storage temperature
TBIAS
Temperature under bias
TSOLDER Soldering temperature
For 10 seconds
Note:
Permanent device damage may occur if Absolute Maximum Ratings are exceeded. Functional operation
should be limited to the Recommended DC Operating Conditions detailed in this data sheet. Exposure to
conditions beyond the operational limits for extended periods of time may affect device reliability.
Absolute Maximum Ratings—bq4285L
Symbol
Parameter
Value
Unit
Conditions
VCC
DC voltage applied on VCC relative to VSS
-0.3 to 6.0
V
DC voltage applied on any pin excluding VCC
relative to VSS
VT
V
T ≤ VCC + 0.3
-0.3 to 6.0
V
TOPR
TSTG
TBIAS
Operating temperature
Storage temperature
Temperature under bias
0 to +70
-55 to +125
-40 to +85
260
°C
°C
°C
°C
Commercial
TSOLDER Soldering temperature
For 10 seconds
Note:
Permanent device damage may occur if Absolute Maximum Ratings are exceeded.
Functional operation should be limited to the Recommended DC Operating Conditions detailed
in this data sheet. Exposure to conditions beyond the operational limits for extended periods of
time may affect device reliability.
12
