bq4285E/L
Capacitance—bq4285E/L (T = 25°C, F = 1MHz, V
= 5.0V)
CC
A
Symbol
CI/O
Parameter
Minimum
Typical
Maximum
Unit
pF
Conditions
VOUT = 0V
VIN = 0V
Input/output capacitance
Input capacitance
-
-
-
-
7
5
CIN
pF
Note:
This parameter is sampled and not 100% tested. It does not include the X1 or X2 pin.
AC Test Conditions—bq4285E
Parameter
Input pulse levels
Test Conditions
0 to 3.0 V
Input rise and fall times
5 ns
Input and output timing reference levels
Output load (including scope and jig)
1.5 V (unless otherwise specified)
See Figures 5 and 6
+5V
+5V
1.15K
960
For all outputs
INT
except INT
50pF
130pF
510
OL-10
OL-11
Figure 6. Output Load B—bq4285E
Figure 5. Output Load A—bq4285E
16
