bq3285ED/LD
Absolute Maximum Ratings—bq3285ED
Symbol
Parameter
Value
Unit
Conditions
VCC
DC voltage applied on VCC relative to VSS
-0.3 to 7.0
V
DC voltage applied on any pin excluding VCC
relative to VSS
VT
-0.3 to 7.0
V
VT ≤ VCC + 0.3
TOPR
TSTG
TBIAS
Operating temperature
Storage temperature
Temperature under bias
0 to +70
-55 to +125
-40 to +85
260
°C
°C
°C
°C
Commercial
TSOLDER Soldering temperature
For 10 seconds
Note:
Permanent device damage may occur if Absolu te Ma xim u m Ra tin gs are exceeded. Functional opera-
tion should be limited to the Recommended DC Operating Conditions detailed in this data sheet. Expo-
sure to conditions beyond the operational limits for extended periods of time may affect device reliability.
Absolute Maximum Ratings—bq3285LD
Symbol
Parameter
Value
Unit
Conditions
VCC
DC voltage applied on VCC relative to VSS
-0.3 to 7.0
V
DC voltage applied on any pin excluding VCC
relative to VSS
VT
-0.3 to 7.0
V
V
T ≤ VCC + 0.3
TOPR
TSTG
TBIAS
Operating temperature
Storage temperature
Temperature under bias
0 to +70
-55 to +125
-40 to +85
260
°C
°C
°C
°C
Commercial
TSOLDER Soldering temperature
For 10 seconds
Note:
Permanent device damage may occur if Absolu te Ma xim u m Ra tin gs are exceeded. Functional opera-
tion should be limited to the Recommended DC Operating Conditions detailed in this data sheet. Expo-
sure to conditions beyond the operational limits for extended periods of time may affect device reliability.
July 1997
11
