Charge Current Control Register REG02 (default 01100000, or 60)
BIT
DESCRIPTION
NOTE
Fast Charge Current Limit
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
ICHG[5]
ICHG[4]
ICHG[3]
ICHG[2]
ICHG[1]
ICHG[0]
BCOLD
2048mA
1024mA
512mA
256mA
128mA
64mA
Offset: 512mA
Range: 512-3008mA (000000 - 100111)
Default: 2048mA (011000)
Note: ICHG higher than 3008mA is not suported
Set Boost Mode temperature monitor threshold
voltage to disable boost mode
Default: Vbcold0 (0)
0 – Vbcold0 (Typ. 76% of REGN or -10◦C w/ 103AT
thermistor )
1 – Vbcold1 (Typ. 79% of REGN or -20◦C w/ 103AT
thermistor)
Bit 0
FORCE_20PCT
0 – ICHG as Fast Charge Current (REG02[7:2])
Default: ICHG as Fast Charge Current (REG02[7:2]) and
and IPRECH as Pre-Charge Current (REG03[7:4]) IPRECH as Pre-Charge Current (REG03[7:4])
programmed
programmed (0)
1 – ICHG as 20% Fast Charge Current
(REG02[7:2]) and IPRECH as 50% Pre-Charge
Current (REG03[7:4]) programmed
Pre-Charge/Termination Current Control Register REG 03 (default 00010001, or 0x11)
BIT
DESCRIPTION
NOTE
Pre-Charge Current Limit
Bit 7
Bit 6
Bit 5
Bit 4
IPRECHG[3] 1024mA
IPRECHG[2] 512mA
Offset: 128mA,
Range: 128mA – 2048mA
Default: 256mA (0001)
IPRECHG[1] 256mA
IPRECHG[0] 128mA
Termination Current Limit
Bit 3
Bit 2
Bit 1
Bit 0
ITERM[3]
ITERM[2]
ITERM[1]
ITERM[0]
1024mA
512mA
256mA
128mA
Offset: 128mA
Range: 128mA – 2048mA
Default: 256mA (0001)
Charge Voltage Control Register REG04 (default 10110010, or 0xB2)
BIT
DESCRIPTION
NOTE
Charge Voltage Limit
Bit 7
Bit 6
Bit 5
Bit 4
Bit 3
Bit 2
Bit 1
VREG[5]
VREG[4]
VREG[3]
VREG[2]
VREG[1]
VREG[0]
BATLOWV
512mV
Offset: 3.504V
Range: 3.504V – 4.400V
Default: 4.208V
256mV
128mV
64mV
32mV
16mV
0 – 2.8V, 1 – 3.0V
Default: 3.0V (1) (pre-charge to fast charge)
Default: 100mV (0)
Battery Recharge Threshold (below battery regulation voltage)
Bit 0 VRECHG 0 – 100mV, 1 – 300mV
