AM6548, AM6528, AM6526
ZHCSLA7B –DECEMBER 2019 –REVISED JUNE 2021
www.ti.com.cn
表6-4. ADC1 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
MCU_ADC1_REFN
DESCRIPTION [2]
ADC Reference Input (negative)
BALL [4]
[3]
A
A
A
A
A
A
A
A
A
A
H3
H2
F4
G6
G4
H5
F5
G5
G3
H4
MCU_ADC1_REFP
MCU_ADC1_AIN0
MCU_ADC1_AIN1
MCU_ADC1_AIN2
MCU_ADC1_AIN3
MCU_ADC1_AIN4
MCU_ADC1_AIN5
MCU_ADC1_AIN6
MCU_ADC1_AIN7
ADC Reference Input (positive)
ADC Analog Input 0
ADC Analog Input 1
ADC Analog Input 2
ADC Analog Input 3
ADC Analog Input 4
ADC Analog Input 5
ADC Analog Input 6
ADC Analog Input 7
6.3.2 CAL
6.3.2.1 MAIN Domain
表6-5. CSI0 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
BALL [4]
[3]
CSI0_RXN0
CSI0_RXN1
CSI0_RXN2
CSI0_RXN3
CSI0_RXN4(1)
CSI0_RXP0
CSI0_RXP1
CSI0_RXP2
CSI0_RXP3
CSI0_RXP4(1)
CSI Differential Receive Input (negative)
CSI Differential Receive Input (negative)
CSI Differential Receive Input (negative)
CSI Differential Receive Input (negative)
CSI Differential Receive Input (negative)
CSI Differential Receive Input (positive)
CSI Differential Receive Input (positive)
CSI Differential Receive Input (positive)
CSI Differential Receive Input (positive)
CSI Differential Receive Input (positive)
I
I
I
I
I
I
I
I
I
I
G28
H27
F26
H25
G24
F28
G27
G26
G25
F24
(1) Line 4 (position 5) supports only data. For more information, see the Camera Adapter Layer (CAL) Subsystem section in the device
TRM.
表6-6. VIN0 Signal Descriptions
PIN TYPE
SIGNAL NAME [1]
DESCRIPTION [2]
Video Input Horizontal Sync
BALL [4]
[3]
VIN0_HD
I
P23
R28
R23
N23
M26
P28
P27
N26
N25
P24
R27
T24
T23
VIN0_PCLK
VIN0_VD
Video Input Pixel Clock
Video Input Vertical Sync
Video Input Data 0
Video Input Data 1
Video Input Data 2
Video Input Data 3
Video Input Data 4
Video Input Data 5
Video Input Data 6
Video Input Data 7
Video Input Data 8
Video Input Data 9
I
I
VIN0_DATA0
VIN0_DATA1
VIN0_DATA2
VIN0_DATA3
VIN0_DATA4
VIN0_DATA5
VIN0_DATA6
VIN0_DATA7
VIN0_DATA8
VIN0_DATA9
I
I
I
I
I
I
I
I
I
I
