AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
SPRS717F –OCTOBER 2011–REVISED APRIL 2013
www.ti.com
•
Transfers to and from External Storage
(EMIF, General-Purpose Memory
Controller, Slave Peripherals)
• Security
– Crypto Hardware Accelerators (AES, SHA,
PKA, RNG)
• Inter-Processor Communication (IPC)
• Boot Modes
– Integrates Hardware-Based Mailbox for IPC
and Spinlock for Process Synchronization
Between the Cortex-A8, PRCM, and PRU-
ICSS
– Boot Mode is Selected via Boot
Configuration Pins Latched on the Rising
Edge of the PWRONRSTn Reset Input Pin
• Packages:
•
Mailbox Registers that Generate
Interrupts
– 298-Pin S-PBGA-N298 Via Channel™
package
(ZCE Suffix), 0.65-mm Ball Pitch
– 324-Pin S-PBGA-N324 package
(ZCZ Suffix), 0.80-mm Ball Pitch
–
Four Initiators (Cortex-A8, PRCM,
PRU0, PRU1)
•
Spinlock has 128 Software-Assigned
Lock Registers
1.2 Applications
•
•
•
•
•
Gaming Peripherals
•
•
•
•
Connected Vending Machines
Weighing Scales
Home and Industrial Automation
Consumer Medical Appliances
Printers
Educational Consoles
Advanced Toys
Smart Toll Systems
4
Device Summary
