AM3359, AM3358, AM3357
AM3356, AM3354, AM3352
www.ti.com
SPRS717F –OCTOBER 2011–REVISED APRIL 2013
5.4 DMTimer
5.4.1 DMTimer Electrical Data and Timing
Table 5-3. Timing Requirements for DMTimer [1-7]
(see Figure 5-2)
NO.
MIN
4P+1(1)
MAX
MAX
UNIT
1
tc(TCLKIN)
Cycle time, TCLKIN
ns
(1) P = period of PICLKOCP (interface clock).
Table 5-4. Switching Characteristics for DMTimer [4-7]
(see Figure 5-2)
NO.
PARAMETER
MIN
4P-3(1)
4P-3(1)
UNIT
ns
2
3
tw(TIMERxH)
tw(TIMERxL)
Pulse duration, high
Pulse duration, low
ns
(1) P = period of PICLKTIMER (functional clock).
1
TCLKIN
2
3
TIMER[x]
Figure 5-2. Timer Timing
Copyright © 2011–2013, Texas Instruments Incorporated
Peripheral Information and Timings
117
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
