Compak Two-chip SIDACtor Device
Compak Two-chip SIDACtor Device
The modified DO-214AA SIDACtor device provides low-cost, longitudinal protection.
1
(T)
2
(G)
SIDACtor devices are used to enable equipment to meet various regulatory requirements
3
including GR 1089, ITU K.20, K.21, and K.45, IEC 60950, UL 60950, and TIA-968 (formerly
(R)
known as FCC Part 68).
Electrical Parameters
VDRM
VS
VDRM
Volts
VS
CO
pF
Volts
Volts
Volts
Part
VT
IDRM
IS
IT
IH
Number
Pins1-2, 2-3
Pins 1-3
Volts
µAmps
mAmps Amps mAmps Pins 1-3
P3002CA
P6002CA
140
275
180
350
280
550
360
700
4
4
5
5
800
800
1
1
120
120
15
15
* For surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured between Pins 1-3 at 1 MHz with a 2 V bias.
UL 60950 creepage requirements must be considered.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
8x20 µs
10x160 µs
10x560 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps
Amps
Amps
Amps/µs
A
150
150
90
50
45
20
500
http://www.teccor.com
+1 972-580-7777
2 - 12
© 2002 Teccor Electronics
®
SIDACtor Data Book and Design Guide
