MicroCapacitance (MC) SA SIDACtor Device
MicroCapacitance (MC) SA SIDACtor Device
The DO-214AA SA MC SIDACtor series is intended for applications sensitive to load
values. Typically, high speed connections require a lower capacitance. CO values for the
MicroCapacitance device are 40% lower than a standard SA part.
This MC SIDACtor series is used to enable equipment to meet various regulatory
requirements including GR 1089, ITU K.20, K.21, and K.45, IEC 60950, UL 60950, and TIA-
968 (formerly known as FCC Part 68).
Electrical Parameters
Part
VDRM
VS
VT
IDRM
IS
IT
IH
CO
pF
Number *
Volts
Volts
Volts
µAmps
mAmps
Amps
mAmps
P0080SA MC
P0300SA MC
6
25
25
40
4
4
5
5
800
800
2.2
2.2
50
50
45
25
* For surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
8x20 µs
10x160 µs
10x560 µs
10x1000 µs
di/dt
Series
Amps
Amps
Amps
Amps
Amps
Amps/µs
A
150
150
90
50
45
20
500
http://www.teccor.com
+1 972-580-7777
2 - 8
© 2002 Teccor Electronics
®
SIDACtor Data Book and Design Guide
