SIDACtor Device
SIDACtor Device
TO-92 SIDACtor solid state protection devices protect telecommunications equipment such
as modems, line cards, fax machines, and other CPE.
SIDACtor devices are used to enable equipment to meet various regulatory requirements
including GR 1089, ITU K.20, K.21, and K.45, IEC 60950, UL 60950, and TIA-968 (formerly
known as FCC Part 68)
.
Electrical Parameters
Part
VDRM
VS
VT
IDRM
IS
IT
IH
CO
pF
Number *
Volts
6
Volts
Volts
µAmps
mAmps
Amps
mAmps
P0080E_
P0300E_
P0640E_
P0720E_
P0900E_
P1100E_
P1300E_
P1500E_
P1800E_
P2300E_
P2600E_
P3100E_
P3500E_
25
40
77
88
98
130
160
180
220
260
300
350
400
4
4
4
4
4
4
4
4
4
4
4
4
4
5
5
5
5
5
5
5
5
5
5
5
5
5
800
800
800
800
800
800
800
800
800
800
800
800
800
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
2.2
50
50
100
110
50
50
50
40
40
40
30
30
30
30
30
25
58
65
75
150
150
150
150
150
150
150
150
150
150
150
90
120
140
170
190
220
275
320
* For individual “EA”, “EB”, and “EC” surge ratings, see table below.
General Notes:
•
•
•
•
•
•
•
All measurements are made at an ambient temperature of 25 °C. IPP applies to -40 °C through +85 °C temperature range.
I
PP is a repetitive surge rating and is guaranteed for the life of the product.
Listed SIDACtor devices are bi-directional. All electrical parameters and surge ratings apply to forward and reverse polarities.
V
DRM is measured at IDRM.
VS is measured at 100 V/µs.
Special voltage (VS and VDRM) and holding current (IH) requirements are available upon request.
Off-state capacitance is measured at 1 MHz with a 2 V bias and is a typical value for “EA” and “EB” product. “EC” capacitance is
approximately 2x the listed value. The off-state capacitance of the P0080EB is equal to the “EC” device.
Surge Ratings
IPP
IPP
IPP
IPP
IPP
ITSM
60 Hz
Amps
2x10 µs
Amps
8x20 µs
Amps
10x160 µs
Amps
10x560 µs
Amps
10x1000 µs
Amps
di/dt
Series
Amps/µs
A
B
C
150
250
500
150
250
400
90
150
200
50
100
150
45
80
100
20
30
50
500
500
500
http://www.teccor.com
+1 972-580-7777
2 - 16
© 2002 Teccor Electronics
SIDACtor Data Book and Design Guide
®
