SM5953
8-Bit Micro-controller
15KB with ISP Flash
& 256B RAM embedded
ET1: ET1=0 – Disable Timer 1 overflow interrupt.
ET1=1 – Enable Timer 1 overflow interrupt.
EX1: EX1=0 – Disable external interrupt 1.
EX1=1 – Enable external interrupt 1.
ET0: ET0=0 – Disable Timer 0 overflow interrupt.
ET0=1 – Enable Timer 0 overflow interrupt.
EX0: EX0=0 – Disable external interrupt 0.
EX0=1 – Enable external interrupt 0.
Mnemonic: IP
Address: B8h
7
-
6
-
5
PT2
4
PS
3
PT1
2
PX1
1
PT0
0
PX0
Reset
00H
PT2: Timer2 interrupt priority bit.
PS: Serial port interrupt priority bit.
PT1: Timer1 interrupt priority bit.
PX1: External interrupt 1 priority bit.
PT0: Timer 0 interrupt priority bit.
PX0: External interrupt 0 priority bit.
Interrupt Priority Table
IP.x
1
Priority Level
1
(highest)
0
2
Specifications subject to change without notice contact your sales representatives for the most recent information.
ISSFD-M074 Ver B SM5953 12/27/2013
- 34 -
