SM39A16M1
8-Bit Micro-controller
16KB with ISP Flash
& 1K+256B RAM embedded
FLTBEN = 0 - Disable Fault B function
FLTBEN = 1 - Enable Fault B function
FLTCON 0 = inactive PWM[5:0]
1 = inactive PWM[7:0]
FLTAS Fault A status, must be cleared by SW(inactive mode)
FLTAS = 0 - No Fault
FLTAS = 1 - FLTA is asserted.
FLTAMOD FLTA Mode Set
FLTAMOD = 0 - inactive mode
FLTAMOD = 1 - cycle-by-cycle mode
FLTAEN FLTA Active Set
FLTAEN = 0 - Disable Fault A function
FLTAEN = 1 - Enable Fault A function
13.6 FLTNF (Fault Noise Filter)
Mnemonic: FLTNF
Address: DCh
7
-
6
5
4
3
2
1
0
Reset
00H
-
FLTBLS
FLTALS
FLTBNF[1:0]
FLTANF[1:0]
FLTBLS:
FLTALS:
Fault B level select
0: active low
1: active high
Fault A level select
0: active low
1: active high
Fault A noise filter
00 = Fosc/1
FLTANF
[1:0]
01 = Fosc/2
10 = Fosc/4
11 = Fosc/8
FLTBNF
[1:0]
Fault B noise filter
00 = Fosc/1
01 = Fosc/2
10 = Fosc/4
11 = Fosc/8
