SM39A16M1
8-Bit Micro-controller
16KB with ISP Flash
& 1K+256B RAM embedded
00 = Fosc/2
01 = Fosc/4
10 = Fosc/8
11 = Fosc/16
Dead Time 2
00_0000 = 1 Dead Time 2 Unit.
00_0001 = 2 Dead Time 2 Units
………….
DT2[5:0]
11_1111 = 64 Dead Time 2 Units.
13.2.4 DEADTIME3 (Dead Time 3 for PWM Pair 3)
Mnemonic: DEADTIME3
Address: ECh
7
6
5
4
3
2
1
0
Reset
00H
DT3PRE[1:0]
DT3[5:0]
DT3PRE[1:0] Dead Time 3 Prescale
00 = Fosc/2
01 = Fosc/4
10 = Fosc/8
11 = Fosc/16
DT3[5:0]
Dead Time 3
00_0000 = 1 Dead Time 3 Unit.
00_0001 = 2 Dead Time 3 Units
………….
11_1111 = 64 Dead Time 3 Units.
13.2.5 OVRIDEDIS (Override Disable)
Mnemonic: OVRIDEDIS
Address: DEh
7
6
5
4
3
2
1
0
Reset
OV7DIS
OV6DIS
OV5DIS
OV4DIS
OV3DIS
OV2DIS
OV1DIS
OV0DIS
FFH
OV7DIS Override Disable 7 Action Selection
OV7DIS = 0 - PWM7 Override Enable
OV7DIS = 1 - PWM7 Override Disable
OV6DIS Override Disable 6 Action Selection
OV6DIS = 0 - PWM6 Override Enable
OV6DIS = 1 - PWM6 Override Disable
OV5DIS Override Disable 5 Action Selection
OV5DIS = 0 - PWM5 Override Enable
OV5DIS = 1 - PWM5 Override Disable
OV4DIS Override Disable 4 Action Selection
OV4DIS = 0 - PWM4 Override Enable
OV4DIS = 1 - PWM4 Override Disable
OV3DIS Override Disable 3 Action Selection
OV3DIS = 0 - PWM3 Override Enable
Specifications subject to change without notice contact your sales representatives for the most recent information.
ISSFD-M069 Ver C SM39A16M1 7/31/2013
- 74 -
