SM39A16M1
8-Bit Micro-controller
16KB with ISP Flash
& 1K+256B RAM embedded
OV0DATA = 0 - PWM0 Override Data
OV0DATA = 1 - PWM0 Override Data
Example: PWM Output overrides waveform.
OVRIDEDIS[7:0] OVRIDEDATA[7:0]
11110000b
11110000b
11110000b
11110000b
Period Cycle
PWMPOLARITY[7:0]
11111111b
11111111b
11111111b
11111111b
1
2
3
4
00000011b
00000110b
00001100b
00001010b
13.2.7 PWMPOLARITY (PWM Polarity)
Mnemonic: PWMPOLARITY
Address: DDh
7
6
5
4
3
2
1
0
Reset
POLARITY7 POLARITY6 POLARITY5 POLARITY4 POLARITY3 POLARITY2 POLARITY1 POLARITY0 FFH
POLARITY7 PWM Polarity 7
POLARITY7 = 0 - PWM7 Polarity active low
POLARITY7 = 1 - PWM7 Polarity active high
POLARITY6 PWM Polarity 6
POLARITY6 =0 - PWM6 Polarity active low
POLARITY6 =1 - PWM6 Polarity active high
POLARITY5 PWM Polarity 5
POLARITY5 = 0 - PWM5 Polarity active low
POLARITY5 = 1 - PWM5 Polarity active high
POLARITY4 PWM Polarity 4
POLARITY4 = 0 - PWM4 Polarity active low
POLARITY4 = 1 - PWM4 Polarity active high
POLARITY3 PWM Polarity 3
POLARITY3 = 0 - PWM3 Polarity active low
POLARITY3 = 1 - PWM3 Polarity active high
POLARITY2 PWM Polarity 2
Specifications subject to change without notice contact your sales representatives for the most recent information.
ISSFD-M069
Ver C SM39A16M1 7/31/2013
- 76 -
