Register description
Figure 11. Basic limiter and volume flow diagram
STA335BW
Table 23. Limiter attack rate as a function
of LxA bits
Table 24. Limiter release rate as a
function of LxR bits
LxA(3..0)
Attack Rate dB/ms
LxR(3..0)
Release Rate dB/ms
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1111
3.1584
2.7072
2.2560
1.8048
1.3536
0.9024
0.4512
0.2256
0.1504
0.1123
0.0902
0.0752
0.0645
0.0564
0.0501
0.0451
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1111
0.5116
0.1370
0.0744
0.0499
0.0360
0.0299
0.0264
0.0208
0.0198
0.0172
0.0147
0.0137
0.0134
0.0117
0.0110
0.0104
Fast
Fast
Slow
Slow
