Register description
STA335BW
5.10
Tone control register (address 0x11)
5.10.1
Tone control
D7
D6
D5
D4
D3
D2
D1
D0
TTC3
0
TTC2
1
TTC1
1
TTC0
1
BTC3
0
BTC2
1
BTC1
1
BTC0
1
Table 22. Tone control boost/cut as a function of BTC and TTC bits
BTC(3..0)/TTC(3..0)
Boost/Cut
0000
0001
…
-12 dB
-12 dB
…
0111
0110
0111
1000
1001
…
-4 dB
-2 dB
0 dB
+2 dB
+4 dB
…
1101
1110
1111
+12 dB
+12 dB
+12 dB
5.11
Dynamics control registers (addresses 0x12 to 0x15)
5.11.1
Limiter 1 attack/release rate
D7
D6
D5
D4
D3
D2
D1
D0
L1A3
0
L1A2
1
L1A1
1
L1A0
0
L1R3
1
L1R2
0
L1R1
1
L1R0
0
5.11.2
Limiter 1 attack/release threshold
D7
D6
D5
D4
D3
D2
D1
D0
L1AT3
0
L1AT2
1
L1AT1
1
L1AT0
0
L1RT3
1
L1RT2
0
L1RT1
0
L1RT0
1
38/54
