STA326
Table 22. Crossover Frequency Selection (continued)
XO (2..0)
1000
1001
1010
1011
1100
1101
1110
1111
Bass Management - Crossover Frequency
220 Hz
240 Hz
260 Hz
280 Hz
300 Hz
320 Hz
340 Hz
360 Hz
7.9.4 Register - Preset EQ Settings (Address 0Dh)
D7
D6
D5
D4
PEQ4
0
D3
PEQ3
0
D2
PEQ2
0
D1
PEQ1
0
D0
PEQ0
0
Table 23. Preset EQ Selection
PEQ (3..0)
00000
00001
00010
00011
00100
00101
00110
00111
01000
01001
01010
01011
01100
01101
01110
01111
10000
10001
10010
10011
10100
10101
10110
10111
11000
11001
11010
11011
11100
11101
11110
11111
Setting
Flat
Rock
Soft Rock
Jazz
Classical
Dance
Pop
Soft
Hard
Party
Vocal
Hip-Hop
Dialog
Bass-Boost #1
Bass-Boost #2
Bass-Boost #3
Loudness 1 (least boost)
Loudness 2
Loudness 3
Loudness 4
Loudness 5
Loudness 6
Loudness 7
Loudness 8
Loudness 9
Loudness 10
Loudness 11
Loudness 12
Loudness 13
Loudness 14
Loudness 15
Loudness 16 (most boost)
25/43
