5 System configuration
ST’s own tools include:
q
q
q
ST40RA
C/C++ compilers,
debugger,
proprietary OS.
Microsoft: WindowsCE,
Sun: JavaOS for consumers,
WindRiver: VxWorks, Tornado tools,
Linux,
Insignia JVM,
ANT browser.
Third parties include:
q
q
q
q
q
q
4.5.2
Software compatibility
SH-4 core software
The ST40RA SH-4 core is binary code compatible with the Hitachi SH775x family.
Standard peripheral driver
The ST40 standard SCIF, timer, real-time clock and PIO are compatible with the ST40 SOC range
of devices and the Hitachi SH775x family.
Bus interface driver
The PCI, LMI, and EMI interfaces are register compatible with the ST40 SOC range of devices.
The ST40RA contains an EMPI and MPX arbiter and MPX clock control unit which are additional to
the bus interface components of the ST40 SOC range of devices.
I/O device driver
The Mailbox is a module with no ST legacy software.
5
System configuration
The ST40RA system address map has been designed to maintain compatibility with existing ST40
family devices and other STMicroelectronics devices.
The SH-4 core and core peripherals maintain compatibility with the ST40 SOC range of devices and
Hitachi SH7750 wherever possible.
Devices listed in
Table 2: ST40RA system address map on page 13
, are documented in the
ST40
System Architecture Manual
as described in
Chapter 2: ST40 documentation suite on page 6
.
Coherency between the cache and external memory is assured by software. The ST40 CPU has
cache control instructions which enable software to do this. Details of these instructions are given in
the
ST40 CPU Core Architecture Manual
.
The ST40RA is run in little endian mode.
11/94
STMicroelectronics
ADCS 7260755H
