ST24E16, ST25E16
Figure 3. Maximum RL Value versus Bus Capacitance (CBUS) for an I2C Bus, fC = 400kHz
20
V
CC
16
R
R
L
L
12
8
SDA
SCL
C
BUS
MASTER
C
BUS
4
0
V
= 5V
CC
25
50
75
100
C
(pF)
AI01115
BUS
DEVICE OPERATION
I2C Bus Background
STOP condition at the end of a Write command
triggers the internal EEPROM write cycle.
Acknowledge Bit (ACK). An acknowledge signal
is used to indicate a successful data transfer. The
bus transmitter, either master or slave, will release
the SDAbus after sending 8 bits of data. During the
9th clock pulse the receiver pulls the SDA bus low
to acknowledge the receipt of the 8 bits of data.
Data Input. During data input the ST24/25E16
sample the SDA bus signal on the rising edge of
the clock SCL. For correct device operation the
SDA signal must be stable during the clock low to
high transition and the data must change ONLY
when the SCL line is low.
Device Selection. To start communication be-
tween the bus master and the slave ST24/25E16,
the master must initiate a START condition. The 8
bits sent after a START condition are made up of a
device select of 4 bits thatidentifies the device type,
3 Chip Enable bits and one bit for a READ (RW =
1) or WRITE (RW = 0) operation. There are two
modes both for read and write. These are summa-
rised in Table 4 and described hereafter. Acommu-
nication between the master and the slave isended
with a STOP condition.
The ST24/25E16 support the extended addressing
I2C protocol. This protocol defines any device that
sends data onto the bus as a transmitter and any
device that reads the data as a receiver.The device
that controls the data transfer is known as the
master and the other as the slave. The master will
always initiate a data transfer and will provide the
serial clock for synchronisation. The ST24/25E16
are always slave devices in all communications.
Start Condition. START is identified by a high to
low transition of the SDA line while the clock SCL
is stable in the high state. A START condition must
precede any command for data transfer. Except
during a programming cycle, the ST24/25E16 con-
tinuously monitor the SDA and SCL signals for a
START condition and will not respond unless one
is given.
Stop Condition. STOPis identified by a low to high
transition of the SDA line while the clock SCL is
stable in the high state. A STOP condition termi-
nates communication between the ST24/25E16
and the bus master. A STOP condition at the end
of a Read command forces the standby state. A
4/16
