P R E L I M I N A R Y
128 Mb Products Based on 110 nm Floating Gate Technology
Valid FBGA Package
Combinations
CE#
Configuration
Package Marking
Temperature
Speed
VIO
Package Type
S29PL127J60TFI13
S29PL127J60TFW13
S29PL127J70TFI13
S29PL127J70TFW13
S29PL127J60TFI13 (-40 - +85 º C)
60
20 x 14 mm
56-pin TSOP
TS056
PL127J60TFW13
PL127J70TFI13
PL127J70TFW13
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
3.0 V
Single CE#
70
64 Mb Products Based on 110 nm Floating Gate Technology
Valid Combinations
BGA Packages
Package Marking
PL064J55BAI12
PL064J55BAW12
PL064J60BAI12
PL064J60BAW12
PL064J70BAI12
PL064J70BAW12
PL064J55BAI15
PL064J55BAW15
PL064J60BAI15
PL064J60BAW15
PL064J70BAI15
PL064J70BAW15
Temperature
Speed
VIO
Package Type
S29PL064J55BAI12
S29PL064J55BAW12
S29PL064J60BAI12
S29PL064J60BAW12
S29PL064J70BAI12
S29PL064J70BAW12
S29PL064J55BAI15
S29PL064J55BAW15
S29PL064J60BAI15
S29PL064J60BAW15
S29PL064J70BAI15
S29PL064J70BAW15
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
55 ns
(Note)
8 x 6 mm
48-ball
Standalone Package
VBK048
60 ns
70 ns
3.0 V
55 ns
(Note)
7 x 9 mm
56-ball
MCP-Compatible
TLC056
60 ns
70 ns
3.0 V
32 Mb Products Based on 110 nm Floating Gate Technology
Valid Combinations
GA Packages
Package Marking
PL032J55BAI12
PL032J55BAW12
PL032J60BAI12
PL032J60BAW12
PL032J70BAI12
PL032J70BAW12
Temperature
Speed
VIO
Package Type
S29PL032J55BAI12
S29PL032J55BAW12
S29PL032J60BAI12
S29PL032J60BAW12
S29PL032J70BAI12
S29PL032J70BAW12
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
(-40 - +85 º C)
(-25 - +85 º C)
55 ns
(Note)
8 x 6 mm
48-ball
Standalone Package
VBK048
60 ns
70 ns
3.0 V
10
S29PL127J/S29PL129J/S29PL064J/S29PL032J
31107A62 April 7, 2005
