A d v a n c e I n f o r m a t i o n
Ordering Information (256 Mb)
The ordering part number is formed by a valid combination of the following:
S29GL256N
90 00
T
A
I
0
PACKING TYPE
0
3
=
=
Tray (standard; see note 1)
13” Tape and Reel
MODEL NUMBER (V range, protection when WP# =V
)
IL
IO
= 2.7 to 3.6 V, highest address sector protected
01
02
V1
V2
=
=
=
=
V
V
V
V
IO
IO
IO
IO
= 2.7 to 3.6 V, lowest address sector protected
= 1.65 to 1.95 V, highest address sector protected
= 1.65 to 1.95 V, lowest address sector protected
L
TEMPERATURE RANGE
I
=
Industrial (–40
°
C to +85 C)
°
PACKAGE MATERIALS SET
A
F
=
=
Standard
Pb-free
PACKAGE TYPE
T
F
=
=
Thin Small Outline Package (TSOP) Standard Pinout
Fortified Ball Grid Array, 1.0 mm pitch package
SPEED OPTION
80
90
10
=
=
=
80 ns
90 ns
100 ns
DEVICE NUMBER/DESCRIPTION
S29GL256N
3.0 Volt-only, 256 Megabit (16 M x 16-Bit/64 M x 8-Bit) Page-Mode Flash Memory
Manufactured on 110 nm MirrorBitTM process technology
S29GL512N Valid Combinations
Package &
Package Description
256 Mb
Speed (ns)
Model Number
Pack Type
Temperature
80, 90
90, 10
01, 02
V1, V2
TS056 (Note 2)
LAA064 (Note 3)
TSOP
Fortified BGA
TAI, TFI
FAI, FFI
S29GL256N
0, 2 (Note 1)
Notes:
1. Type 0 is standard. Specify other options as required.
2. TSOP package marking omits packing type designator from ordering part number.
3. BGA package marking omits leading “S29” and packing type designator from ordering part number.
Valid Combinations
Valid Combinations list configurations planned to be supported in volume for this device.
Consult your local sales office to confirm availability of specific valid combinations and to
check on newly released combinations.
May 13, 2004 27631A4
S29GLxxxN MirrorBitTM Flash Family
