A d v a n c e I n f o r m a t i o n
Ordering Information (512 Mb)
The ordering part number is formed by a valid combination of the following:
S29GL512N
10 00
F
A
I
0
PACKING TYPE
0
3
=
=
Tray (standard; see note 1)
13” Tape and Reel
MODEL NUMBER (V range, protection when WP# =V
)
IL
IO
= 2.7 to 3.6 V, highest address sector protected
01
02
V1
V2
=
=
=
=
V
V
V
V
IO
IO
IO
IO
= 2.7 to 3.6 V, lowest address sector protected
= 1.65 to 1.95 V, highest address sector protected
= 1.65 to 1.95 V, lowest address sector protected
L
TEMPERATURE RANGE
I
=
Industrial (–40
°
C to +85 C)
°
PACKAGE MATERIALS SET
A
F
=
=
Standard
Pb-free
PACKAGE TYPE
T
F
=
=
Thin Small Outline Package (TSOP) Standard Pinout
Fortified Ball Grid Array, 1.0 mm pitch package
SPEED OPTION
90
10
11
=
=
=
90 ns
100 ns
110 ns
DEVICE NUMBER/DESCRIPTION
S29GL512N
3.0 Volt-only, 512 Megabit (32 M x 16-Bit/64 M x 8-Bit) Page-Mode Flash Memory
Manufactured on 110 nm MirrorBitTM process technology
S29GL512N Valid Combinations
Package &
Package Description
512 Mb
Speed (ns)
Model Number
Pack Type
Temperature
90, 10
10, 11
01, 02
V1, V2
TS056 (Note 2)
LAA064 (Note 3)
TSOP
TAI, TFI
FAI, FFI
S29GL512N
0, 3 (Note 1)
Fortified BGA
Notes:
1. Type 0 is standard. Specify other options as required.
2. TSOP package marking omits packing type designator from ordering part number.
3. BGA package marking omits leading “S29” and packing type designator from ordering part number.
Valid Combinations
Valid Combinations list configurations planned to be supported in volume for this device.
Consult your local sales office to confirm availability of specific valid combinations and to
check on newly released combinations.
12
S29GLxxxN MirrorBitTM Flash Family
27631A4 May 13, 2004
