Ordering Information
For S29CD032G0R valid combination in the PQFP package, changed clock fre-
quency from 77 to 75 MHz. In Fortified BGA packages valid combinations table,
replaced TBDs with package markings; also changed additional ordering options.
Device Bus Operations
Table 5, S29CD032G Autoselect Codes (High Voltage Method): Corrected order-
ing option to 01 for data 00001h.
Burst CLK Edge Data Delivery: Deleted reference to delivering data on falling
edge.
Table 9, Configuration Register Definitions, CR2–CR0: deleted configuration 111.
SecSi™ (Secured Silicon) Sector Protection: Corrected the SecSi Sector address
ranges in the first paragraph.
Table 13, Sector Addresses for Ordering Option 01: Corrected address ranges for
sector SA71, SA73, SA75, and SA77.
Command Definitions
Sector Erase and Program Suspend Operation Mechanics: Deleted bullets at be-
ginning of section referring to erase pulses.
Synchronous (Burst) Read Operation
In second sentence of first paragraph, changed “linear” to “linear and continu-
ous”. In third sentence, changed “are configurable as” to “are configurable as
linear burst accesses”; sentence now ends after this phrase.
AC Characteristics
Asynchronous Read Operations table: Corrected test setup for t to a minimum
RC
specification. Replaced TBD for t , option 0R with actual value. Changed t for
OE
CE
option 0R to 52 ns.
Burst Mode Read table: Deleted t
and t
specifications. Deleted note below
IACC
BDH
table. Changed specifications for all speeds on parameters t
, t
, t
,
ADVCS ADVCH DS
t
t
, t , t
, and t
. Changed t
specification for 0R speed option, Changed
AH CS ACS
ACH
CLK
specification for 0J speed option. Deleted “falling” from t
description.
OE
ADVCS
Changed description of t
.
ACH
Burst Mode Read table: Changed specifications for the following: t
; t
,
ADVCH
IACC
options 0M and 0J; t ; t , all options; t ; t ; t
, all options.
AS AH
CS CH CES
Figure 16, Burst Mode Read (x32 Mode): Renamed period t
to t
.
DVCH
BDH
Hardware Reset (RESET#) table: Deleted t
, t , t
, t
.
READY RH DRNE RMX
Erase/Program Operations table: Changed t , t , t , t , t , t , t , t
WC AS DS CS CH AH WP WHWH1
and t
specifications. t
specification now has word and double-word
WHWH2
WHWH1
values. Deleted t
and “CE# Setup to CLK” parameters.
OES
Alternate CE# Controlled Erase/Program Operations table: Changed t , t
,
WC
AS
t
, t , t , t , t
and t
specifications. t
specification now
WS WH WP CP WHWH1
WHWH2
WHWH1
has word and double-word values. Deleted t
parameters.
, t
, t
, and t
WADVH WCKS
OES
WADVS
Ordering Information
Added packing type designators for Tray, 7-in. and 13-in. tape and reel
configurations.
