11.1.4 CONFIGURATION SEQUENCE
To program the configuration registers, the following sequence must be followed:
1. Enter Configuration Mode
2. Configure the Configuration Registers
3. Exit Configuration Mode.
11.1.5 Enter Configuration Mode
To place the chip into the Configuration State the Config Key is sent to the chip’s CONFIG PORT. The config key
consists of 0x55 written to the CONFIG PORT. Once the configuration key is received correctly the chip enters into
the Configuration State (The auto Config ports are enabled).
11.1.6 Configuration Mode
The system sets the logical device information and activates desired logical devices through the INDEX and DATA
ports. In configuration mode, the INDEX PORT is located at the CONFIG PORT address and the DATA PORT is at
INDEX PORT address + 1.
The desired configuration registers are accessed in two steps:
a) Write the index of the Logical Device Number Configuration Register (i.e., 0x00 for FDC) to the INDEX
PORT and then write the number of the desired logical device to the DATA PORT
b) Write the address of the desired configuration register within the logical device to the INDEX PORT and
then write or read the configuration register through the DATA PORT.
Note:
If accessing the Global Configuration Registers, step (a) is not required.
11.1.7 Exit Configuration Mode
To exit the Configuration State the system writes 0xAA to the CONFIG PORT. The chip returns to the RUN State.
Note:
Only two states are defined (Run and Configuration). In the Run State the chip will always be ready to enter the
Configuration State.
