7.23.1 Timing Diagrams For SER_IRQ Cycle
A) Start Frame timing with source sampled a low pulse on IRQ1
START FRAME
IRQ0 FRAME IRQ1 FRAME IRQ2 FRAME
SL
or
H
R
T
S
R
T
S
R
T
S
R
T
H
PCI_CLK
1
START
SER_IRQ
Drive Source
IRQ1
Host Controller
None
IRQ1
None
Note: H=Host Control; R=Recovery; T=Turn-Around; SL=Slave Control; S=Sample
Note 1: Start Frame pulse can be 4-8 clocks wide depending on the location of the device in the PCI bridge
hierarchy in a synchronous bridge design.
B) Stop Frame Timing with Host using 17 SER_IRQ sampling period
IRQ14
IRQ15
IOCHCK#
FRAME
STOP FRAME
NEXT CYCLE
FRAME
FRAME
I 2
S
R
T
S
R
T
S
R
T
H
R
T
PCI_CLK
SER_IRQ
1
3
STOP
START
None
IRQ15
None
Host Controller
Driver
Note: H=Host Control; R=Recovery; T=Turn-Around; S=Sample; I=Idle
Note 1: The next SER_IRQ cycle’s Start Frame pulse may or may not start immediately after the turn-
around clock of the Stop Frame.
Note 2: There may be none, one or more Idle states during the Stop Frame.
Note 3: Stop pulse is 2 clocks wide for Quiet mode, 3 clocks wide for Continuous mode.
7.23.2 SER_IRQ Cycle Control
There are two modes of operation for the SER_IRQ Start Frame:
1) Quiet (Active) Mode: Any device may initiate a Start Frame by driving the SER_IRQ low for one clock,
while the SER_IRQ is Idle. After driving low for one clock the SER_IRQ must immediately be tri-stated
without at any time driving high. A Start Frame may not be initiated while the SER_IRQ is Active. The
SER_IRQ is Idle between Stop and Start Frames. The SER_IRQ is Active between Start and Stop
Frames. This mode of operation allows the SER_IRQ to be Idle when there are no IRQ/Data transitions
which should be most of the time.
Once a Start Frame has been initiated the Host Controller will take over driving the SER_IRQ low in the
next clock and will continue driving the SER_IRQ low for a programmable period of three to seven clocks.
This makes a total low pulse width of four to eight clocks. Finally, the Host Controller will drive the
SER_IRQ back high for one clock, then tri-state.
