Advanced I/O Controller with Motherboard GLUE Logic
Datasheet
Note that all FIFO data transfers are byte wide and byte aligned. Address/RLE transfers are byte-wide
and only allowed in the forward direction.
The host may switch directions by first switching to mode = 001, negotiating for the forward or reverse
channel, setting direction to 1 or 0, then setting mode = 011. When direction is 1 the hardware shall
handshake for each ECP read data byte and attempt to fill the FIFO. Bytes may then be read from the
ecpDFifo as long as it is not empty.
ECP transfers may also be accomplished (albeit slowly) by handshaking individual bytes under program
control in mode = 001, or 000.
7.15 Termination from ECP Mode
Termination from ECP Mode is similar to the termination from Nibble/Byte Modes. The host is permitted to
terminate from ECP Mode only in specific well-defined states. The termination can only be executed while
the bus is in the forward direction. To terminate while the channel is in the reverse direction, it must first be
transitioned into the forward direction.
7.16 Command/Data
ECP Mode supports two advanced features to improve the effectiveness of the protocol for some
applications. The features are implemented by allowing the transfer of normal 8 bit data or 8 bit
commands.
When in the forward direction, normal data is transferred when HostAck is high and an 8 bit command is
transferred when HostAck is low.
The most significant bit of the command indicates whether it is a run-length count (for compression) or a
channel address.
When in the reverse direction, normal data is transferred when PeriphAck is high and an 8 bit command is
transferred when PeriphAck is low. The most significant bit of the command is always zero. Reverse
channel addresses are seldom used and may not be supported in hardware.
Table 7.9 - Channel/Data Commands supported in ECP mode
Forward Channel Commands (HostAck Low)
Reverse Channel Commands (PeripAck Low)
D7
0
D[6:0]
Run-Length Count (0-127)
(mode 0011 0X00 only)
1
Channel Address (0-127)
7.17 Data Compression
The ECP port supports run length encoded (RLE) decompression in hardware and can transfer
compressed data to a peripheral. Run length encoded (RLE) compression in hardware is not supported.
To transfer compressed data in ECP mode, the compression count is written to the ecpAFifo and the data
byte is written to the ecpDFifo.
SMSC LPC47M182
111
Revision 1.8 SMSC/Non-SMSC Register Sets (02-24-05)
DATASHEET
