Three Port 10/100 Managed Ethernet Switch with MII
Datasheet
Table 4.2 Soft-Strap Configuration Strap Definitions (continued)
PIN / DEFAULT
VALUE
STRAP NAME
DESCRIPTION
FD_FC_strap_mii
Port 0(External MII) Full-Duplex Flow Control Enable
Strap: Configures the default of the TX_FC_MII and
RX_FC_MII bits in the Port 0(External MII) Manual Flow
Control Register (MANUAL_FC_MII) which are used when
manual full-duplex flow control is selected. When
configured low, flow control is disabled on RX/TX. When
configured high, flow control is enabled on RX/TX.
FD_FC_MII
manual_FC_strap_mii
Port 0(External MII) Manual Flow Control Enable Strap:
Configures the default value of the MANUAL_FC_MII bit in
the Port 0(External MII) Manual Flow Control Register
(MANUAL_FC_MII). When configured low, flow control is
determined by Virtual Auto-Negotiation (if enabled). When
configured high, flow control is determined by TX_FC_MII
and RX_FC_MII bits in the Port 0(External MII) Manual
Flow Control Register (MANUAL_FC_MII).
MANUAL_FC_MII
Note:
In MAC mode, this strap is not used. In this mode,
the Virtual PHY is not applicable, and full-duplex
flow control must be controlled manually by the
host, based upon the external PHYs Auto-
negotiation results.
SQE_test_disable_strap_mii
SQE Heartbeat Disable Strap: Configures the Signal
Quality Error (Heartbeat) test function by controlling the
default value of the SQEOFF (bit 0) of the Virtual PHY
Special Control/Status Register
0b
(VPHY_SPECIAL_CONTROL_STATUS). When configured
low, SQEOFF defaults to 0 and SQE test is enabled. When
configured high, SQEOFF defaults to 1 and SQE test is
disabled.
4.2.4.2
Hard-Straps
Hard-straps are latched upon Power-On Reset (POR) or pin reset (nRST) only. Unlike soft-straps,
hard-straps always have an associated pin and cannot be overridden by the EEPROM Loader. These
straps are used as either direct configuration values or as register defaults. Table 4.3 provides a list of
all hard-straps and their associated pin. These straps, along with their pin assignments are also fully
defined in Chapter 3, "Pin Description and Configuration," on page 26.
Table 4.3 Hard-Strap Configuration Strap Definitions
STRAP NAME
DESCRIPTION
PIN
mngt_mode_strap[1:0]
Serial Management Mode Strap: Configures the default
serial management mode.
MNGT_MODE[1:0]
00 = Unmanaged mode
01 = SMI Managed Mode
10 = I2C Managed Mode
11 = SPI Managed Mode
Refer to Section 2.3, "Modes of Operation," on page 23 for
additional information on the various modes of the
LAN9313/LAN9313i.
eeprom_type_strap
Revision 1.2 (04-08-08)
EEPROM Type Strap: Configures the EEPROM type.
EEPROM_TYPE
0 = Microwire Mode
1 = I2C Mode
DATA5S0HEET
SMSC LAN9313/LAN9313i
