13.1.3
EEPROM
This section details the EEPROM related System CSR’s. These registers should only be used if an
EEPROM has been connected to the LAN9313/LAN9313i. Refer to chapter Section 8.2, "I2C/Microwire
2
Master EEPROM Controller," on page 101 for additional information on the various modes (I C and
Microwire) of the EEPROM Controller (EPC).
13.1.3.1
EEPROM Command Register (E2P_CMD)
Offset:
1B4h
Size:
32 bits
This read/write register is used to control the read and write operations of the serial EEPROM.
BITS
DESCRIPTION
TYPE
DEFAULT
31
EEPROM Controller Busy (EPC_BUSY)
R/W
SC
0b
When a 1 is written into this bit, the operation specified in the
EPC_COMMAND field of this register is performed at the specified
EEPROM address. This bit will remain set until the selected operation is
complete. In the case of a read, this indicates that the Host can read valid
data from the EEPROM Data Register (E2P_DATA). The E2P_CMD and
E2P_DATA registers should not be modified until this bit is cleared. In the
case where a write is attempted and an EEPROM is not present, the
EPC_BUSY bit remains set until the EEPROM Controller Timeout
(EPC_TIMEOUT) bit is set. At this time the EPC_BUSY bit is cleared.
Note:
EPC_BUSY is set immediately following power-up, or pin reset, or
DIGITAL_RST reset. After the EEPROM Loader has finished
loading, the EPC_BUSY bit is cleared. Refer to chapter Section
8.2.4, "EEPROM Loader," on page 113 for more information.
