PHY Mode I C/SPI Managed
2
In PHY mode I C or SPI managed, the Port 1/2 PHYs are accessed via the PMI, and the Virtual PHY
is accessed via the external MII management pins. The SMI slave is not used in these modes.
2
The Virtual PHY and PMI parallel interfaces are accessible via the I C/SPI slave interfaces or the
EEPROM Loader. Refer to Section 8.3, "SPI/I2C Slave Controller," on page 118 and Section 8.2.4,
"EEPROM Loader," on page 113 for additional information.
Figure 9.3 details the MII multiplexer management path connections for this mode.
