Three Port 10/100 Managed Ethernet Switch with MII
Datasheet
9.4.5
PHY Mode SMI Managed
In PHY mode SMI managed, the internal PHYs, Virtual PHY, and SMI slave block are accessed via
the MII management pins. The PMI is not used in this mode.
The Virtual PHY interface is accessible via the SMI slave or the EEPROM Loader. Refer to Section
9.2, "SMI Slave Controller," on page 125 and Section 8.2.4, "EEPROM Loader," on page 113 for
additional information.
Figure 9.2 details the MII multiplexer management path connections for this mode.
MII Pins
MDIO_DIR
MDI
SMI Slave
MDO
MDO
MDIO_DIR
MDIO
MDC
Parallel
Master
MDCLK
MDI
MDC_DIR
MDC_OUT
MDC_IN
MDI
Virtual PHY
MDO
Management
Mode Selection
MDIO_DIR
Parallel
Slave
MDCLK
MDI
PHY2
MDO
MDIO_DIR
MDCLK
MDI
PHY1
MDO
MDIO_DIR
MDCLK
Management
Mode Selection
MDO MDCLK MDI MDO_EnN
PMI
Parallel Slave
Figure 9.5 MII Mux Management Path Connections - PHY Mode SMI Managed
Revision 1.2 (04-08-08)
132
SMSC LAN9313/LAN9313i
DATASHEET
