Three Port 10/100 Managed Ethernet Switch with MII
Datasheet
9.4.4
PHY Mode Unmanaged
In PHY mode unmanaged, the Virtual PHY is accessed via the external MII management pins. The
Port 1/2 PHYs, SMI slave, and the PMI are not used in this mode.
The Virtual PHY interface is accessible via the EEPROM Loader. Refer to Section 8.2.4, "EEPROM
Loader," on page 113 for additional information.
Figure 9.4 details the MII multiplexer management path connections for this mode.
MII Pins
MDIO_DIR
MDI
SMI Slave
MDO
MDO
MDIO_DIR
MDIO
MDC
Parallel
Master
MDCLK
MDI
MDC_DIR
MDC_OUT
MDC_IN
MDI
Virtual PHY
MDO
Management
Mode Selection
MDIO_DIR
Parallel
Slave
MDCLK
MDI
PHY2
MDO
MDIO_DIR
MDCLK
MDI
PHY1
MDO
MDIO_DIR
MDCLK
Management
Mode Selection
MDO MDCLK MDI MDO_EnN
PMI
Parallel Slave
Figure 9.4 MII Mux Management Path Connections - PHY Mode Unmanaged
SMSC LAN9313/LAN9313i
131
Revision 1.2 (04-08-08)
DATASHEET
