Non-PCI Single-Chip Full Duplex Ethernet Controller with Magic Packet
Chapter 11 Operational Description
11.1 Maximum Guaranteed Ratings*
Operating Temperature Range ...................................................................................................0°C to 70°C
Storage Temperature Range ...............................................................................................-55°C to +150°C
Lead Temperature Range (soldering, 10 seconds) ............................................................................+325°C
Positive Voltage on any pin, with respect to Ground .....................................................................VCC + 0.3V
Negative Voltage on any pin, with respect to Ground ........................................................................... -0.3V
Maximum VCC .......................................................................................................................................... +7V
*Stresses above those listed above could cause permanent damage to the device. This is a stress rating
only and functional operation of the device at any other condition above those indicated in the operation
sections of this specification is not implied.
Note:
When powering this device from laboratory or system power supplies, it is important that the Absolute
Maximum Ratings not be exceeded or device failure can result. Some power supplies exhibit voltage
spikes on their outputs when the AC power is switched on or off. In addition, voltage transients on the AC
power line may appear on the DC output. If this possibility exists, it is suggested that a clamp circuit be
used.
11.2 DC Electrical Characteristics
(TA =0°C to 70°C, VCC = +5.0 V ± 10%, or VCC = +3.3 V ± 10% as noted for Revisions E and later)
PARAMETER
Input Voltage Levels for Vcc = 5.0V
I Type Input Buffer
SYMBOL MIN
TYP
MAX
UNITS
COMMENTS
Low Input Level
VILI
0.8
V
V
TTL Levels
High Input Level
IS Type Input Buffer
VIHI
2.0
2.2
Low Input Level
VILIS
VIHIS
VHYS
0.8
V
V
Schmitt Trigger
Schmitt Trigger
High Input Level
Schmitt Trigger Hysteresis
250
mV
