requests from the Parallel Port to the CPU due
to a low to high transition on the nACK input.
Refer to the description of the interrupt under
Operation, Interrupts.
tFifo (Test FIFO Mode)
ADDRESS OFFSET = 400H
Mode = 110
Data bytes may be read, written or DMAed to or
from the system to this FIFO in any direction.
Data in the tFIFO will not be transmitted to the
to the parallel port lines using a hardware
protocol handshake.
tFIFO may be displayed on the parallel port data
lines.
BIT 5 DIRECTION
If mode=000 or mode=010, this bit has no effect
and the direction is always out regardless of the
state of this bit. In all other modes, Direction is
valid and a logic 0 means that the printer port is
in output mode (write); a logic 1 means that the
printer port is in input mode (read).
However, data in the
The tFIFO will not stall when overwritten or
underrun. If an attempt is made to write data to
a full tFIFO, the new data is not accepted into
the tFIFO. If an attempt is made to read data
from an empty tFIFO, the last data byte is re-
read again. The full and empty bits must
always keep track of the correct FIFO state. The
tFIFO will transfer data at the maximum ISA
rate so that software may generate performance
metrics.
during a read are a low level, and
Bits 6 and 7
cannot be written.
cFifo (Parallel Port Data FIFO)
ADDRESS OFFSET = 400h
Mode = 010
Bytes written or DMAed from the system to this
FIFO are transmitted by a hardware handshake
to the peripheral using the standard parallel port
The FIFO size and interrupt threshold can be
determined by writing bytes to the FIFO and
checking the full and serviceIntr bits.
protocol.
Transfers to the FIFO are byte
aligned. This mode is only defined for the
forward direction.
The writeIntrThreshold can be determined by
starting with a full tFIFO, setting the direction bit
to 0 and emptying it a byte at a time until
ecpDFifo (ECP Data FIFO)
ADDRESS OFFSET = 400H
Mode = 011
is set.
This may generate a
serviceIntr
spurious interrupt, but will indicate that the
threshold has been reached.
Bytes written or DMAed from the system to this
FIFO, when the direction bit is 0, are transmitted
by a hardware handshake to the peripheral
using the ECP parallel port protocol. Transfers
to the FIFO are byte aligned.
The readIntrThreshold can be determined by
setting the direction bit to 1 and filling the empty
tFIFO a byte at a time until
is set.
serviceIntr
This may generate a spurious interrupt, but will
indicate that the threshold has been reached.
Data bytes from the peripheral are read under
automatic hardware handshake from ECP into
this FIFO when the direction bit is 1. Reads or
DMAs from the FIFO will return bytes of ECP
data to the system.
101
