11.1.20 Frame Rate and Color Control (R2Bh)
Frame Rate and Color Control (R2Bh)
RS
/WR
/RD D15 D14 D13 D12 D11 D10 D9
D8
D7
D6
D5
D4
0
D3
D2
D1
D0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
FRS3 FRS2 FRS1 FRS0
1
↑
1
0
0
0
0
0
1
0
0
0
Default value
FRS[3:0] :Set the frame rate when the internal resistor is used for oscillator circuit.
FRS[3:0]
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1111
Frame Rate
27.5
29.3
33
36.7
40.3
44
47.7
51.3
55
64.2
73.3
82.5
91.7
100.8
110
Description
114.1
