ST7669V
9.1.39 FirstCom: First Com. Page address (B1H)
Command
FirstCom
Parameter
A0
0
/RD /WR
D7
1
D6
0
D5
1
D4
1
D3
0
D2
0
D1
0
D0
1
Hex
(B1h)
-
1
1
0
0
1
F7
F6
F5
F4
F3
F2
F1
F0
Description
This command defines the first output COM number that mapping to the RAM page
address 0. For detail setting value, please see the table as below.
F7
0
F6
0
F5
0
F4
0
F3
0
F2
0
F1
0
F0
0
Line address
0
1
0
0
0
0
0
0
0
1
0
0
0
0
0
0
1
0
2
:
:
:
:
:
:
:
:
:
1
0
1
0
1
1
1
0
160
161
1
0
1
0
1
1
1
1
Example:
If FirstCom=8, common 8 would output the data of RAM page address 0.
Restriction
Register
Status
Availability
Availability
Normal Mode On, Idle Mode Off, Sleep Out
Normal Mode On, Idle Mode On, Sleep Out
Partial Mode On, Idle Mode Off, Sleep Out
Partial Mode On, Idle Mode On, Sleep Out
Sleep In
Yes
Yes
Yes
Yes
Yes
Default
Status
Default Value (F[7:0])
Power On Sequence
00h
00h
00h
S/W Reset
H/W Reset
Flow Chart
Ver 1.3
134/208
6/4/2008
SITRONIX [ SITRONIX TECHNOLOGY CO., LTD. ]
