ST7565S
THE MPU INTERFACE (REFERENCE EXAMPLES)
The ST7565S Series can be connected to either 80X86 Series MPUs or to 68000 Series MPUs. Moreover, using the serial
interface it is possible to operate the ST7565S series chips with fewer signal lines.
The display area can be enlarged by using multiple ST7565S Series chips. When this is done, the chip select signal can be
used to select the individual ICs to access.
(1) 8080 Series MPUs
VDD
V
CC
V
DD
A0
A0
C86
A1 to A7
IORQ
CS1
CS2
Decoder
DO to D7
RD
DO to D7
RD
WR
WR
RES
RES
P/S
GND
V
SS
RESET
V
SS
Figure 42-1
(2) 6800 Series MPUs
V
DD
V
CC
VDD
A0
A0
C86
A1 to A15
VMA
CS1
CS2
Decoder
DO to D7
E
R/W
DO to D7
E
R/W
RES
RES
P/S
GND
VSS
RESET
V
SS
Figure 42-2
(3) Using the Serial Interface
VDD or VSS
VCC
VDD
A0
A0
C86
CS1
CS2
A1 to A7
Decoder
Port 1
Port 2
RES
SI
SCL
RES
P/S
GND
V
SS
RESET
V
SS
Figure 42-3
