7. Package Outline: 16-Pin Narrow Body SOIC
Figure 40 illustrates the package details for the Si824x in a 16-pin narrow-body SOIC (SO-16). Table 13 lists the
values for the dimensions shown in the illustration.
Figure 40. 16-pin Small Outline Integrated Circuit (SOIC) Package
Table 13. Package Diagram Dimensions
Dimension
Min
—
Max
1.75
0.25
—
Dimension
Min
Max
A
L
0.40
1.27
A1
0.10
1.25
0.31
0.17
L2
0.25 BSC
A2
h
0.25
0°
0.50
8°
b
0.51
0.25
θ
c
aaa
bbb
ccc
ddd
0.10
0.20
0.10
0.25
D
E
9.90 BSC
6.00 BSC
3.90 BSC
1.27 BSC
E1
e
Notes:
1. All dimensions shown are in millimeters (mm) unless otherwise noted.
2. Dimensioning and Tolerancing per ANSI Y14.5M-1994.
3. This drawing conforms to the JEDEC Solid State Outline MS-012, Variation AC.
4. Recommended card reflow profile is per the JEDEC/IPC J-STD-020 specification for Small Body Components.
